ELEWIND 22mm Stainless steel 3 Pin terminal illuminated micro travel push button switch (PM22-11WE/RG/12V/S)

Short Description:

ELEWIND 22mm illuminated micro travel push button switch (PM22-11WE/RG/12V/S)

Part number:PM22-11WE/RG/12V/S

Install diameter:22mm

Switch rating: 1A/125VAC,  0.5A/250VAC

Shape: Flat head

Function: Momentary Micro travel (1NO1NC)

Terminal: 3 Pin terminal

LED color: Red-green

LED voltage: 12V

Operation travel: about 0.5mm

Crust material:Stainless steel

IP rating: IP67

Temperature: – 40 to 75 Degree
